Parkinglift Model TP
The parking lift model TP triple stacker refers to a simple lifting type mechanical parking equipment installed on the ground, without the need for excavation of pits, and built directly on the existing ground, which can provide 3-level parking spaces. This type of equipment achieves the goal of stacking 3 cars on the ground space of the same parking space through mechanical devices such as lifting.
Specifications:
- Place of Origin: Shandong, China
- Product name: Triple stacker parking lift
- Brand: Tada
- Model: TP
- Warranty: 1 year
- Load Capacity: 2000kg-3000kg
- Dimensions of cars: 5300mmx1900mmx1900mm
- Certification: CE MEA ISO
- Drive Mode: Hydraulic-driven
- Power Supply: 3 phase 5 line
- Operation Voltage: 24V
- Surface Treatment: Spray painting or hot-dip galvanizing
Extended Applications:
1 set of triple stackers in one group type
Multiple sets of triple stackers in one group type
Technical support:
The user manuals, operation training, online support, fault diagnosis guidance, on-site installation guidance, etc
How does it work:
Vehicle storage process: After the vehicle enters the lowest parking space, the driver and passengers leave the vehicle and start the equipment through the control system. At this point, the lower loading plate rises to leave space for the middle-level vehicles, which are then raised to the top level as well. In this way, each layer can store a car in sequence.
